  • Flexible Mounting Structure

    SolFirsTech Double Layer Flexible Mounting Structure

    Technical Details Installation  Ground Foundation  PHC/Cast-in-place Pile Modules Layout  Single Row in Portrait Single span  ≤50m Wind Load  0.45KN/㎡ (Adjustable according to the project) Snow Load  0.15KN/㎡ (Adjustable according to the project) Tilt Angle  ≤15° Standards  GB 50009-2012、GB 50017-2017、NB/T 10115-2018、JGJ257-2012、JGJT 497-2023 Material  Anodized Aluminum AL6005-T5, Hot Dip Galvanized Steel, Zn-Al-Mg pre-coated steel,Stainless Steel SUS304 Warranty  10 Years Warranty

    Hot Tags : Flexible Mounting Structure Double Layer

    Read More
  • Flexible Mounting Structure

    SolFirsTech Single Layer Flexible Mounting Structure

    Technical Details Installation  Ground Foundation  PHC/Cast-in-place Pile Modules Layout  Single Row in Portrait Single span  ≤20m Wind Load  0.45KN/㎡ (Adjustable according to the project) Snow Load  0.15KN/㎡ (Adjustable according to the project) Tilt Angle  ≤30° Standards  GB 50009-2012、GB 50017-2017、NB/T 10115-2018、JGJ257-2012、JGJT 497-2023 Material  Anodized Aluminum AL6005-T5, Hot Dip Galvanized Steel, Zn-Al-Mg pre-coated steel,Stainless Steel SUS304 Warranty  10 Years Warranty

    Hot Tags : Single Layer

    Read More
  • Solar Tracker

    Tilt Series Tilted Single Axis Solar Tracking Systems

    Features & Characteristics High Stability  Triangle supports and simple structure for higher stability Reliability  The independent control system help to monitor the operation,find fault points in time, and reduce power output loss Smart Tracking  Adjust tilt angle smartly and timely according to terrain and weather Tracker Structure Tracking Technology Tilted Single Axis Tracker System Voltage 1000V/1500V Tracking Range ±45° Inclination Angle Azimuth 5-25° Working Wind Speed 18 m/s (Customizable) Max. Wind Speed 40 m/s (ASCE 7-10) Modules per Tracker W20 Modules (Customizable) Principal Materials Hot-Dip Galvanized Q235B/Q355B Zn-Al-Mg Coated Steel Mean Coating Thickness ≥65 micron Drive System Slewing Drive Foundation type PHC / Cast-in-Place Pile / Steel Pile Control System Control System MCU Tracking Mode Closed Loop Time Control + GPS Tracking Accuracy <2。 Communication Wireless (ZigBee, LoRa); Wired (RS485) Powder Acquisition External Supply / String Supply / Self-Powered Auto Stow at Night Yes Auto Stow During High Winds Yes Optimized Backtracking Yes Protection Degree IP65 Working Temperature -30°C-65°C Anemometer Yes Power Consumption 0.3kWh per day Project Reference

    Hot Tags : Single Axis Solar Tracking System Solar Photovoltaic Tracking Systems Tilted Single Axis Tracker

    Read More
  • Solar Tracker

    Duo Series Dual Axis Solar Tracking Systems

    Features & Characteristics High Adaptability   Adapt to almost all terrain High Stability  Herringbone structure, multi-point support, square mesh shape design Accessibility  Obstacle-free among independent trackers, easy for construction and maintenance Reliability    Adjust tilt angle smartly and timely according to terrain and weather data to increase power output Smart Tracking  Adjust tilt angle smartly and timely according to terrain and weather data to increase power output Tracker Structure Tracking Technology Dual Axis Tracker System Voltage 1000V/1500V Tracking Range Azimuth ±120°, Elevation 0-60° Working Wind Speed 18 m/s (Customizable) Max. Wind Speed 35 m/s (ASCE 7-10) Modules per Tracker W40 Modules (Customizable) Principal Materials Hot-Dip Galvanized Q235B/Q355B, Zn-Al-Mg Coated Steel Mean Coating Thickness ≥65 micron Drive System Independent Foundation Foundation type PHC / Cast-in-Place Pile / Steel Pile Control System Control System MCU Tracking Mode Closed Loop Time Control + GPS Tracking Accuracy <2° Communication Wireless (ZigBee, LoRa); Wired (RS485) Powder Acquisition External Supply / String Supply / Self-Powered Auto Stow at Night Yes Auto Stow During High Winds Yes Optimized Backtracking Yes Protection Degree IP65 Working Temperature -30°C-65°C Anemometer Yes Power Consumption 0.5kWh per day Project Reference

    Hot Tags : Dual Axis Solar Tracking System Dual Axis Solar Trackers Residential Solar Tracker

    Read More
  • Solar Tracker

    Horizon S Series Linked Single Axis Solar Tracking Systems

    Features & Characteristics High Capacity Every two trackers are linked for up to 4 strings of modules (120 pieces) Compatibility  Compatible to 182/210mm cell solar modules High Stability Be equipped with damper to reduce resonance under extreme environment Reliability  The independent control system help to monitor the operation, find fault points in time, and reduce power output loss Smart Tracking  Adjust tilt angle smartly and timely according to terrain and weather data to increase power output Reasonable Design   The stability is ensured via exclusive structural design and strict wind tunnel test Tracker Structure Tracking Technology Horizontal Single Axis Tracker System Voltage 1000V/1500V Tracking Range ±50° Working Wind Speed 18 m/s (Customizable) Max. Wind Speed 45m/s (ASCE7-10) Max. Wind Speed <120 Modules (Customizable) Principal Materials Hot-Dip Galvanized Q235B/Q355B, Zn-Al-Mg Coated Steel Mean Coating Thickness ≥65 micron Drive System Linear Actuator Foundation type PHC / Cast-in-Place Pile / Steel Pile Control System Control System MCU Tracking Mode Closed Loop Time Control + GPS Tracking Accuracy <2° Communication Wireless (ZigBee, LoRa); Wired (RS485) Powder Acquisition External Supply / String Supply / Self-Powered Auto Stow at Night Yes Auto Stow During High Winds Yes Optimized Backtracking Yes Protection Degree IP65 Working Temperature -30°C-65°C Anemometer Yes Power Consumption 0.3kWh per day Project Reference

    Hot Tags : Horizon S Series Solar Tracking Systems Dual-Axis Solar Tracker

    Read More
  • Solar Tracker

    Horizon D+ Series Multi-Point Drive Single Axis Solar Tracking Systems

    Features & Characteristics High Adaptability High Adaptability  Gradient difference adaptability to uneven terrain in N-S direction up to 15% High Stability  The multi-point drive greatly increase the wind torsion resistance and critical wind speed Compatibility  Compatible to 182/210mm cell solar modules Accessibility  Obstacle-free among independent trackers, easy for construction and maintenance Reliability  The independent control system help to monitor the operation, find fault points in time, and reduce power output loss Smart Tracking  Adjust tilt angle smartly and timely according to terrain and weather data to increase power output Reasonable Design  The stability is ensured via exclusive structural design and strict wind tunnel test Tracker Structure Tracking Technology Horizontal Single Axis Tracker System Voltage 1000V/1500V Tracking Range ±45° Working Wind Speed 18 m/s (Customizable) Max. Wind Speed 45 m/s (ASCE 7-10) Modules per Tracker ≤120 Modules (Customizable) Principal Materials Hot-Dip Galvanized Q235B/Q355B, Zn-AI-Mg Coated Steel Mean Coating Thickness ≥65 micron Drive System Slewing Drive / Linear Actuator Foundation type PHC / Cast-in-Place Pile / Steel Pile Control System Control System MCU Tracking Mode Closed Loop Time Control + GPS Tracking Accuracy <2° Communication Wireless (ZigBee, LoRa); Wired (RS485) Powder Acquisition External Supply / String Supply / Self-Powered Auto Stow at Night Yes Auto Stow During High Winds Yes Optimized Backtracking Yes Protection Degree IP65 Working Temperature -30°C-65°C Anemometer Yes Power Consumption 0.3kWh per day Project Reference
    Read More
  • Solar Tracker

    Horizon D Series Single Point Drive Single Axis Solar Tracking Systems

    Features & Characteristics High Adaptability  Gradient difference adaptability to uneven terrain in N-S direction up to 15% Less Piles  The 2P module design saves pile foundations (to 140 pcs/MW) and greatly reduce the cost Compatibility   Compatible to 182/210mm cell solar modules Accessibility  Obstacle-free among independent trackers, easy for construction and maintenance Reliability   The independent control system help to monitor the operation, find fault points in time, and reduce power output loss Smart Tracking   Adjust tilt angle smartly and timely according to terrain and weather data to increase power output Reasonable Design  The stability is ensured via exclusive structural design and strict wind tunnel test. Tracker Structure Tracking Technology Horizontal Single Axis Tracker System Voltage 1000V/1500V Tracking Range ±45°/±60° Working Wind Speed 18 m/s (Customizable) Max. Wind Speed 35 m/s (ASCE 7-10) Modules per Tracker ≤60 Modules(Customizable) Principal Materials Hot-Dip Galvanized Q235B/Q355B, Zn-AI-Mg Coated Steel Mean Coating Thickness ≥65 micron Drive System Slewing Drive Foundation type PHC / Cast-in-Place Pile / Steel Pile Control System Control System MCU Tracking Mode Closed Loop Time Control + GPS Tracking Accuracy <2° Communication Wireless (ZigBee, LoRa); Wired (RS485) Powder Acquisition External Supply / String Supply / Self-Powered Auto Stow at Night Yes Auto Stow During High Winds Yes Optimized Backtracking Yes Protection Degree IP65 Working Temperature -30°C-65°C Anemometer Yes Power Consumption 0.3kWh per day
    Read More
  • Floating Solar Mount

    SolFirsTech FLOATING SOLAR MOUNT (TGW03)

    Floating Mounting System Structure Anchoring System Combiner Box Bracket, Cable Trunking, Aisle Types of Trunkings Technical Details Design Description: 1. Reduce water evaporation, and utilize the cooling effect of water to increase the power generation. 2. The bracket is made of aluminum alloy for fireproof. 3. Easy to install without heavy equipment; safe and convenient to maintain. Installation Water Surface Surface Wave Height ≤0.5m Surface Flow Rate ≤0.5m/s Wind Load ≤36m/s Snow Load ≤0.45kn/m² Tilt Angle 0~25° Standards GB50009-2012,EN1990:2002,ASE7-05,AS/NZS1170,JIS C8955:2017 Material HDPE, Anodized Aluminum AL6005-T5, Stainless Steel SUS304 Warranty 10 Years Warranty Project Reference

    Hot Tags : FLOATING SOLAR MOUNT

    Read More
  • C-Steel Ground Mount

    SolFirsTech C-STEEL GROUND MOUNT - SCREW PILE FOUNDATION

    Installation Steps Accessories Technical Details Installation  Ground Foundation  Screw Pile / Concrete Wind Load  up to 60m/s Snow Load  1.4kn/m² Standards  GB50009-2012,EN1990:2002,ASE7-05,AS/NZS1170,JIS C8955:2017,GB50017-2017 Material  Anodized Aluminum AL6005-T5, Hot Dip Galvanized Steel, Zn-Al-Mg pre-coated steel,Stainless Steel SUS304 Warranty  10 Years Warranty

    Hot Tags : C-STEEL GROUND MOUNT

    Read More
  • FENCE

    SolFirsTech FENCE

    Why Fence ·To effectively protect personnel safety both inside and outside the project site. ·To prevent theft.

    Hot Tags : FENCE Straight Fence large metal fence

    Read More
  • Floating Solar Mount

    SolFirsTech FLOATING SOLAR MOUNT (TGW02)

    This series of products are mounting solutions for installing solar photovoltaic modules, inverters, combiner boxes, tranSolFirsTechormers, cables on water, such as dams, lakes, ponds, reservoirs, and coal mining subsidence areas.

    Hot Tags : Floating solar PV mounting System Floating solar mounting system Floating System Floating mounting system Floating PV mounting system floating solar PV power plant

    Read More
  • Floating Solar Mount

    SolFirsTech FLOATING SOLAR MOUNT (TGW01)

    The floating photovoltaic system on the water is different from the photovoltaic power generation projects on the ground and roof. With the declining use of land resources, the land available for the construction of photovoltaic power plants will become increasingly scarce in the future. At the same time, the advantages of floating photovoltaic systems on water are slowly gaining attention from the photovoltaic industry.

    Hot Tags : HDPE solar mount floating solar mounting system Solar mounting floater Water solar mounting Floating solar mounting Structure Floating solar system

    Read More
