Item NO.:
SF-GL-15WPayment:
L/C, T/T, D/P, Western Union, PaypalProduct Origin:
ChinaColor:
NormalShipping Port:
Xiamen,ChinaLead Time:
20-30 working days
General Advantages
1.All in one design - perfect combination of solar power, LED ,LiFePO4 battery, motion sensor, lighting sensor and timing control technology.
2.Easy installation and less labor costs- integrated design without cabling;- can be installed on wood, bamboo, iron post. Or mounted on wall i.e vertical surface, eg. Outside of house, garage- rain-proof, rust-proof structure, maintenance free for permanent installation.
3.Long life span -solar garden light using high power capacity and long life LiFePO4 battery. High-temperature characteristic-this type of battery has good stability and great high-temperature characteristic.
Save energy--integrates infrared sensor to save power and lighting performance. When there is no people working at saving mode, when motion sensed working at bright mode.
|
Outdoor waterproof solar garden light specifications |
||||
|
Model |
SolFirsTech-GL-5W |
SolFirsTech-GL-7W |
SolFirsTech-GL-15W |
|
|
Solar Panle |
Max Power |
18W | 27W | 54W |
|
Solar cell |
Semi-flexible Monocrystalline Silicon Solar Panel |
|||
|
Life time |
25 years |
|||
|
LED Light |
Power |
5W |
7W |
15W |
|
|
|
|||
|
Life time |
50,000 hours |
|||
|
Battery |
Capacity |
36Ah 12V |
54Ah 12V |
72Ah 12V |
|
Type |
Lithium battery |
|||
|
Life time |
5-8 years |
|||
|
Charging |
By sun |
6-10 hours effective sunlight |
||
|
Work temp |
Range(℃) |
-40℃ - +70℃ |
||
|
Colour temp |
Range(k) |
4200K-6500K |
||
|
Installation Height |
Range (m) |
6-8m |
8-10m |
10-15m |
|
Work mode |
Light on at dusk, light off at dawn auto.
Motion sensor mode, Dimming mode,Time control mode for choice.
|
|||
|
Material |
Hot Dip galvanizing | |||
|
Certificate |
CE / ROHS / IP65 | |||
Aluminum Waterproof Solar Street LED Light, simple design,practical,powered by solar, saving energy and environmental friendly.
Wind and Solar two charging mode Solar Street Light
All in one Integrated Solar Street Light, all-in-one design, easy to install. Outdoor light is waterproof.
LED Solar Street Light,simple design,practical,easy installation,powered by solar, saving energy and environmental friendly.
All in one Waterproof Solar Street LED Light,all-in-one design, the light and the solar panel of integrated solar street light are integrated into one structure, which is easy to install.
Why Fence ·To effectively protect personnel safety both inside and outside the project site. ·To prevent theft.
Solar L Feet is common used in Roof Solar System, it is the connector of rail and roof.
Characteristics ·Patented lens, bat-wing light distribution, light is well-distributed ·Intelligent control system to reduce the power consumption of the whole lamp ·Whole lamp is easy to assemble and easy to maintain ·High cycle times, economical and practical Application ·Road lighting ·Landscape lighting ·Schools ·Remote countryside ·Agriculture and animal husbandry Wind-solar Hybrid Street Light Specifications Solar panel power 120W±15% 150W±15% 240W±15% 300W±15% Horizontal axis wind turbine 200W 300W 400W 500W Wind and solar hybrid controller 1 SET Battery capacity 12V/150Ah 12V/100Ahx2 12V/150Ahx2 12V/200Ahx2 Battery Type Lead-acid batteries(Gel) Main light power 40W 50W 80W 100W Color temperature 4000K Height of the whole lamp 7.0m 8.0m 9.0m 10.0m Operating temperature -20°C~55°C Windproof strength 27m/s（Wind Grade 10) Rainy days 5〜7 days
Outstanding quality of stainless steel and aluminum ensures the most durable mounting. Please choose the suitable product for your roof. Or just tell us your roof details and we'll pick up the most suitable one for you.
Features & Characteristics High Adaptability High Adaptability Gradient difference adaptability to uneven terrain in N-S direction up to 15% High Stability The multi-point drive greatly increase the wind torsion resistance and critical wind speed Compatibility Compatible to 182/210mm cell solar modules Accessibility Obstacle-free among independent trackers, easy for construction and maintenance Reliability The independent control system help to monitor the operation, find fault points in time, and reduce power output loss Smart Tracking Adjust tilt angle smartly and timely according to terrain and weather data to increase power output Reasonable Design The stability is ensured via exclusive structural design and strict wind tunnel test Tracker Structure Tracking Technology Horizontal Single Axis Tracker System Voltage 1000V/1500V Tracking Range ±45° Working Wind Speed 18 m/s (Customizable) Max. Wind Speed 45 m/s (ASCE 7-10) Modules per Tracker ≤120 Modules (Customizable) Principal Materials Hot-Dip Galvanized Q235B/Q355B, Zn-AI-Mg Coated Steel Mean Coating Thickness ≥65 micron Drive System Slewing Drive / Linear Actuator Foundation type PHC / Cast-in-Place Pile / Steel Pile Control System Control System MCU Tracking Mode Closed Loop Time Control + GPS Tracking Accuracy <2° Communication Wireless (ZigBee, LoRa); Wired (RS485) Powder Acquisition External Supply / String Supply / Self-Powered Auto Stow at Night Yes Auto Stow During High Winds Yes Optimized Backtracking Yes Protection Degree IP65 Working Temperature -30°C-65°C Anemometer Yes Power Consumption 0.3kWh per day Project Reference
DRAINAGE OF WATER ON CARPORT Technical Details Design description: The main bracket of the carport is made of high-strength carbon steel, the rail and waterproof system are designed with aluminum alloy to meet customers' requirements for safety, installation convenience and aesthetics. Its special structural design allows multiple cars to be freely combined as a unit to maximize the use of space. Installation Ground Foundation Concrete Wind Load up to 60m/s Snow Load 1.4kn/m² Standards GB50009-2012, EN1990:2002, ASE7-05, AS/NZS1170, JIS C8955:2017, GB50017-2017 Material Anodized AL6005-T5, Hot Dip Gavanized Steel，Stainless Steel SUS304 Warranty 10 Years Warranty Project Reference
Characteristics ·Strong reactive power compensation ability, power factor adjustable range ± 0.8 ·Multiple communication methods are flexible and optional (RS485, Ethernet, GPRS/Wi-Fi) ·Support remote upgrade ·With PID repair, improve module performance ·Equipped with AC and DC switch, maintenance is safer and more convenient ·100% selection of world-renowned components, long service life Application ·Distributed ·Roofs ·Hotels ·Factories ·Resorts ·Commercial buildings ·Conference centers ·Office buildings System power 40KW 50KW 60KW 80KW 100KW Solar panel power 400W 420W 450W 450W 450W Number of solar panels 100 PCS 120 PCS 134 PCS 178 PCS 222 PCS Photovoltaic DC cable 1 SET MC4 connector 1 SET Rated output power of inverter 33KW 40KW 50KW 70KW 80KW Maximum output apparent power 36.3KVA 44KVA 55KVA 77KVA 88KVA Rated grid voltage 3/N/PE,400V Grid voltage range 270-480Vac Rated grid frequency 50HZ Grid frequency range 45-65HZ Maximum efficiency 98.60% Island effect protection YES DC reverse connection protection YES AC short circuit protection YES Leakage current protection YES Ingress protection level IP66 Working temperature System Cooling method Natural cooling Maximum working altitude -25～+60℃ Communication 4G (optional)/WiFi (optional) AC output copper core cable 1 SET Distribution box 1 SET Auxiliary material 1 SET Photovoltaic mounting type Aluminum /Carbon steel mounting (one set)
