Characteristics
·MCU dual-core design,excellent performance
·Utility power mode (mains mode)/energy-saving mode/battery mode can be switched, and the application is flexible
·Pure sine wave AC output, which can adapt to various types of loads
·Wide input voltage range, high-precision output, fully automatic voltage
stabilization function
·The LCD module displays the operating parameters of the equipment in real time,
clear operation status indication
·All-round protection function (battery overcharge, high voltage, low voltage protection, overload protection, short circuit protection, over temperature protection)
Application
·Home
·School
·Street
·Frontier defense
·Pastoral area
·Industrial equipment
·Satellite communication equipment
·Ships and other new energy power generation fields
System Parameters
|
System power |
1KW |
3KW |
5KW |
10KW |
15KW |
20KW |
|
|
Solar panel power |
335W |
420W |
|||||
|
Number of solar panels |
3 PCS |
9 PCS |
12 PCS |
24 PCS |
36 PCS |
48 PCS |
|
|
Photovoltaic DC cable |
1 SET |
||||||
|
MC4 connector |
1 SET |
||||||
|
DC combiner box |
1 SET |
||||||
|
Controller |
24V40A |
48V60A |
96V50A |
216V50A |
216V75A |
216V100A |
|
|
Lithium battery/Lead-acid battery(Gel) |
24V |
48V |
96V |
216V |
|||
|
Battery capacity |
200Ah |
250Ah |
200Ah |
300Ah |
400Ah |
||
|
Inverter AC input side voltage |
170-275V |
||||||
|
Inverter AC input side frequency |
45-65Hz |
||||||
|
Inverter off-grid rated output power |
0.8KW |
2. 4KW |
4KW |
8KW |
12KW |
16KW |
|
|
Maximum output apparent power on off-grid side |
1KVA30S |
3KVA30s |
5KVA30s |
10KVA10min |
15KVA10min |
20KVA10min |
|
|
Rated output voltage on off-grid side |
1/N/PE, 220V |
||||||
|
Rated output frequency on off-grid side |
50Hz |
||||||
|
Working temperature |
0 ~+40 °C |
||||||
|
Cooling method |
Air-cooling |
||||||
|
AC output copper core cable |
1 SET |
||||||
|
Distribution box |
1 SET |
||||||
|
Auxiliary material |
1 SET |
||||||
|
Photovoltaic bracket type |
Aluminum /Carbon steel bracket (one set) |
||||||
|
Electrical loads for 3KW off-grid solar system |
|||||||
|
Electrical equipment |
No. |
Power（W） |
Daily Expense (h) |
Total electricity consumption（Wh） |
|||
|
Desk fan |
2 |
45 |
5 |
450 |
|||
|
LED lights |
4 |
2/3/5Z7 |
6 |
204 |
|||
|
TV set |
1
|
100 |
4 |
400 |
|||
|
Micro-wave oven |
600 |
0.5 |
300 |
||||
|
Juicer |
300 |
0.6 |
180 |
||||
|
Refrigerator |
150 |
24 |
150*24*0.8=2880 |
||||
|
Air conditioner |
1100 |
6 |
1100*6*0. 8=5280 |
||||
|
Total electricity consumption |
9694 |
||||||
Characteristics ·DSP itelligent control inverter technology, with excellent performance ·Pure sine wave AC output, with strong adaptability to load ·LCD+LED display mode, with clear indication of operating status of the equipment ·With output overload protection, various automatic protections and alarms ·Intelligent charging control, programmable charging parameter points to meet the special requirements of different occasions ·Battery can be set with multiple protection parameters, with password protection function Application ·Large-scale solar power generation applications such as industrial and mining ·Border defense ·Pastoral areas ·Islands ·Telecommunication base stations System Parameters System power 10KW 15KW 20KW 30KW 50KW Solar panel power 420W Number of solar panels 24 PCS 36 PCS 48 PCS 72 PCS 120 PCS Photovoltaic DC cable 1 SET MC4 connector 1 SET DC combiner box 1 SET Controller 216V50A 216V75A 216V100A 216V150A 348V150A Lithium battery/Lead-acid battery(Gel) 216V 348V Battery capacity 200Ah 300Ah 400Ah 600AH Inverter AC input side voltage 304-456V Inverter AC input side frequency 45-65Hz Inverter off-grid rated output power 8KW 12KW 16KW 24KW 40KW Maximum output apparent power on off-grid side 10KVA10min 15KVA10min 20KVA10min 30KVA10min 50KVA10min Rated output voltage on off-grid side 3/N/PE,380/400 Rated output frequency on off-grid side 50Hz Working temperature 0~+40*C Cooling method Air-cooling AC output copper core cable 1 SET Distribution box 1 SET Auxiliary material 1 SET Photovoltaic mounting type Aluminum /Carbon steel mounting (one set)
Work with thin film solar module, glass-glass solar module, frame less solar module No.q` Product Name Picture SolFirsTech-BM-EC80 End Clamp Kit for Frameless Module SolFirsTech-BM-IC80 Mid Clamp Kit for Frameless Module SolFirsTech-MC-HP12 Mid Clamp Kit SolFirsTech-MC-HP18 End Clamp Kit SolFirsTech-MC-SolFirsTech71 End Clamp Kit SolFirsTech-MCSolFirsTech70 Mid Clamp Kit SolFirsTech-EC-F35-50 Adjustable End Clamp Kit
SolFirsTech Aluminum Carport Mounting Systems specializes in manufacturing and designing to meet the needs of various pole mount installation.
Installation Site Roof Type Non Adjustable Size Customized Color Nature Material SUS304 Certification ISO9001 Warantty 10 Years and 20 years service life
Solar Carports offers a fexible,simple and affordable solution for Solar Mounting System. Solar carports utilize exisiting parking areas to generate renewable power and provide shaded or covered parking for autos,electric charges,on gird mw solar systems.
Flashing on Roof Technical Details Design Description: Apply the flashing to prevent water leakage effectively. Installation Metal Roof Wind Load up to 60m/s Snow Load 1.4kn/m² Standards GB50009-2012, EN1990:2002, ASE7-05, AS/NZS1170, JIS C8955:2017, GB50429-2007 Material Anodized Aluminum AL 6005-T5, Stainless Steel SUS304 Warranty 10 Years Warranty
Easy installation,all kinds of length Hot Dip Galvanized Ground Screw Pile.
This solution is also applicable on ground or concrete roof with small inclination. Its structure is light with high strength and good flexibility.
One of the best things you can do for the long-term success of a photovoltaic (PV) system is to prioritize wire management during the installation process. SolFirsTech-CC-01 SolFirsTech-CC-02 SolFirsTech-CC-03 SolFirsTech-CC-04 SolFirsTech-CC-05
SolFirsTechPVROOF is a series of aluminum waterproof sheds which combine building structure and power generation, and provide functions of windproof, snowproof, waterproof, light transmission. This series has compact structure, great appearance and high adaptability to most sites. Waterproof structure + solar photovoltaic， an eco- friendly substitution to the traditional canopy.
Different Tile Roof require different Tile Hook, based on Tile Roof mould,you can choose suitable hook as per your roof type.
SolFirsTechPVROOM series PV sunrooms are built with tempered glass and metal frame structure. The sunroom solutions provide functions of power generation, windproof, snowproof, waterproof, light transmission. This series has compact structure, great appearance and high adaptability to most sites. Tempered glass + metal frame structure + solar photovoltaic, an eco-friendly substitution to the traditional sunroom.
